Photoelectric-Sensor-Cylindrical-Diffuse-OGH500

Photoelectric Sensor, Cylindrical, Diffuse

IFM Part No : OGH500

Circuit Type: PNP

IP Rating: 67

Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On

Max. Load Current: 200 mA

Operating Frequency: 1,000 Hz

Electrical Connection: Quick Disconnect M12 Connector

Description
Specifications

Cylindrical Photoelectric Sensor, Sensing Method - Cylindrical Photoelectric Sensor Diffuse, Operating Mode - Photoelectric Sensor Selectable Light On/Dark On, Diameter - Cylindrical Photoelectric Sensor 18 mm, Power Requirement - Cylindrical Photoelectric Sensor 10 to 36V DC, Electrical Connection - Cylindrical Photoelectric Sensor 4-Pin M12 Male Connector, Circuit Type - Cylindrical Photoelectric Sensor PNP, Max. Sensing Distance - Cylindrical Photoelectric Sensor 300 mm

Circuit Type: PNP
IP Rating: 67
Operating Mode - Photoelectric Sensor: Selectable Light On/Dark On
Max. Load Current: 200 mA
Operating Frequency: 1,000 Hz
Electrical Connection: Quick Disconnect M12 Connector
Standards: CE Approval, CUL Listed
Features: PEI Lens, Reverse Polarity and Overload Protection
Power Requirement - Cylindrical Photoelectric Sensor: 10 to 36V DC
Min. Object Size: 25mm dia Light Spot
Sensing Method - Cylindrical Photoelectric Sensor: Diffuse
Shape: Cylindrical
Light Source: Red LED
Length: 72.00mm
Sensing Method: Diffuse
Electrical Connection - Cylindrical Photoelectric Sensor: 4-Pin M12 Male Connector
NEMA Rating: Not Rated
Length - Cylindrical Photoelectric Sensor: 72 mm
Max. Sensing Distance - Cylindrical Photoelectric Sensor: 300 mm
Operating Temp. Range: -25 Degrees to 80 Degrees C
Circuit Type - Cylindrical Photoelectric Sensor: PNP
Diameter - Cylindrical Photoelectric Sensor: 18 mm
Diameter: 18mm
Body Material: 316L Stainless Steel

Photoelectric Sensor, Cylindrical, Diffuse
