Digital Pressure Sensor, Power Required 18 to 30V DC, Range -14.5 to 14.5 psi, Compatible With Air and Liquids, Circuit Type PNP/NPN, Output Current 150mA, 200mA @ 60 Degrees C, 250mA @ 40 Degrees C, Contact Form (2) SPST, On Set Point -14.3 to 14.5 psi, Off Set Point -14.4 to 14.4 psi, Burst Pressure 725 psi, Process Connection 1/4 in NPT, IP Rating 65/67, Housing Material Stainless Steel, Wetted Materials Ceramic, Fluorocarbon, Electrical Connection 4 Pin M12 Connector
- Item: Digital Pressure Sensor
- Range: -14.5 to 14.5 psi
- Power Required: 18 to 30V DC
- Process Connection: 1/4 in NPT
- Electrical Connection: 4 Pin M12 Connector
- IP Rating: 65/67
- Off Set Point: -14.4 to 14.4 psi
- On Set Point: -14.3 to 14.5 psi
- Burst Pressure: 725 psi
- Compatible With: Air and Liquids
- Output Current: 150mA, 200mA @ 60 Degrees C, 250mA @ 40 Degrees C
- Housing Material: Stainless Steel
- Temp. Range: -13 Degrees to 176 Degrees F
- Contact Form: (2) SPST
- Wetted Materials: Ceramic, Fluorocarbon
- Circuit Type: PNP/NPN
