Proximity Sensor, Capacitive, 34mm, NO

Omron Part No : E2K-C25MY1

Item: Cylindrical Proximity Sensor

Proximity Sensor Style: Cylindrical Proximity Sensor

Proximity Sensing Method: Capacitive

Cylindrical Proximity Sensor, Capacitive, 34.0 mm, Proximity Sensor Power Requirement 90 to 250V AC, Unshielded, Proximity Sensor Operating Frequency 10 Hz, Proximity Sensor Output Circuit Type 2 Wire, Max. Detecting Distance 25.0 mm, Proximity Sensor Electrical Connection 2m Cable, Output Mode NO, NEMA Rating 1, 12, 13, 4, IP Rating 66, Case Material Plastic, Length 89 mm, Operating Temp. Range -13 Degrees to 158 Degrees F, Max. Current Load 200mA


  • Proximity Sensor Style: Cylindrical Proximity Sensor
  • Proximity Sensing Method: Capacitive
  • Proximity Sensor Power Requirement: 90 to 250V AC
  • Proximity Sensor Output Circuit Type: 2 Wire
  • Output Mode: NO
  • Proximity Sensor Diameter: 34.0 mm
  • Length: 89 mm
  • Max. Detecting Distance: 25.0 mm
  • Proximity Sensor Electrical Connection: 2m Cable
  • Basic Proximity Sensor Case Material: Plastic
  • Shielded / Unshielded: Unshielded
  • Proximity Sensor Operating Frequency: 10 Hz
  • Case Material: Plastic
  • NEMA Rating: 1, 12, 13, 4
  • Max. Current Load: 200mA
  • Operating Temp. Range: -13 Degrees to 158 Degrees F
  • Description/Special Features: Includes L Shaped Bracket
