Time Delay Rlay, 240VAC, 10A, DPDT, 0.1 sec.

Dayton Part No : 24EP39

Function - Timing Relay: Repeat Cycle (On First)

Coil Volts: 240V AC

AC Contact Rating - Relay: 10A @ 240V

DC Contact Rating - Relay: 10A @ 30V

Base Type - Plug In Relay: Octal

Number of Pins - Relay: 8

Adjustment Method - Timer: Potentiometer

Description
Specifications

Single Function Time Delay Relay, Function - Timing Relay Repeat Cycle (On First), Coil Volts 240VAC, AC Contact Rating - Relay 10A @ 240V, DC Contact Rating - Relay 10A @ 30V, Base Type - Plug In Relay Octal, Number of Pins - Relay 8, Mounting - Relay Plug In, Contact Form - Relay DPDT, Power Consumption - Relay 2.0VA, Adjustment Method - Timer Potentiometer, Min. Time Setting - Timer 0.10 sec., Max. Time Setting - Timer 10 sec., Status Indicator None, Contact Material Silver Nickel

Function - Timing Relay: Repeat Cycle (On First)
Coil Volts: 240V AC
AC Contact Rating - Relay: 10A @ 240V
DC Contact Rating - Relay: 10A @ 30V
Base Type - Plug In Relay: Octal
Number of Pins - Relay: 8
Adjustment Method - Timer: Potentiometer
Mounting - Relay: Plug In
Contact Form - Relay: DPDT
Min. Time Setting - Timer: 0.1 sec
Max. Time Setting - Timer: 10 sec
Power Consumption - Relay: 2.0 VA
Pins: 8
Overall Height - Relay: 3.1 in
Socket Code: A
Adjustment Method: Potentiometer
Socket: 1EGP3, 1EGP5, 5X852
Operating Functions: 7
Contact Amp Rating (Resistive): 10A
Contact Material: Silver Nickel
Item: Single Function Time Delay Relay
Base Type: Octal
Function: Repeat Cycle (On First)
Min. Time Setting: 0.10 sec.
Standards: CE, CSA, UR
Status Indicator: None
Coil Rating: 2VA
Electrical Connection: Socket
Hz: 50/60
Body Height - Relay: 2.9 in
Body Width - Relay: 2.4 in
Mounting: plug In
Body Depth - Relay: 1.7 in
Hz - Electrical: 50 Hz, 60 Hz
Max. Time Setting: 10 sec.

Time Delay Rlay, 240VAC, 10A, DPDT, 0.1 sec.
